Whenever using the machine
Check that the switch is NOT in the ‘ON/1’ position before connecting the machine to the •
power supply.
Always keep the power cord out of the way of the tool’s moving parts.•
Immediately switch off the machine when:
The plug or power cord is defective or damaged.•
The switch is defective.•
You smell smoke or burning insulation•
Electrical safety
When using electric machines always observe the safety regulations applicable in your country
to reduce the risk of fire, electric shock and personal injury. Read the following safety
instructions and also the enclosed safety instructions.
Always check that the power supply corresponds to the voltage on the rating plate.
Replacing cables or plugs
Immediately throw away old cables or plugs when they have been replaced by new ones. It is
dangerous to insert the plug of a loose cable in the wall outlet.
Using extension cables
Only use an approved extension cable suitable for the power input of the machine. The
minimum conductor size is 1.5 mm
2
. When using a cable reel always unwind the reel
completely.
Technical specifications
Voltage 230 V - 240 V ~
Frequency 50 Hz
Power input 150 W
Rotational speed, not loaded 2950/min
Duty time S
2
= 30 min
Grinding wheel dimensions
Ø 150x16 mm
Spindle hole diameter
Ø 12.7 mm
Weight 6.0 kg
Lpa (Sound pressure level) 62.6 + 3 dB(A)
Lwa (acoustic power) 75.6 + 3 db(A)
Loadfactor S
2
= 30 min
