Tavool MD50 - Page 3

2
ATTENTION:
* For different measurement targets and test environment, the range and
accuracy will be affected. The measuring accuracy is higher than or equal to
the industry standard in the factory test environment.
*Industry Standard: When measurement range is within 10m, the
measurement accuracy is ±2mm; More than 10m, the measurement
accuracy is calculated as follows: ±2mm±0.05 * (D-10) (D is the measurement distance, unit: m).
Measuring Reference
√
Silence Function
√
Historical Data Review
20Groups
Error Code
√
Battery Power Indication
√
Laser Auto Switch of
30s
Instrument Auto Switch off
180s
Measuring Range
50m: 0.05m-50m
70m: 0.05m-70m
Measuring Accuracy
±2.0mm
Measuring Unit
m,ft,in
Area Unit
m²,ft²
Volume Unit
m³,ft³
Laser Type
620~690nm
Laser Class
class II ,<1mW
Operating Temperature
0~+40℃
Storage Temperature
-20~+65℃
Batteries
AAA(Alkaline),2×1.5V
Working time(Fully charged)
>5000 times
Weight (Without batteries)
Approximate 72g
Dimension (L*W*H)
110X46X25mm
