6.3.- SEALING (Drawing 11)
The pulse generator also has got different sealing possibilities. Three of these
possibilities are showed in Drawing 11.
6.4.- TECHNICAL CHARACTERISTICS
The main technical characteristics of the pulse generator are:
sensor type: Hall effect cell
Number of pulses / revolution: 4 with double impulses train
Feeding voltage: 4 to 18 V
Consumption at 5 V: 10 mA
