Taylor C009 Service Manual

23
Model C009
Controls
LED Status Indicators o n Membrane Panel
There are two status LED's on each membrane panel. There is one panel on the left for the left head and one on
the right for the right head, for a total of four status LED's. Each pair is made up of a Service LED and a
Concentrate Out LED.
Membrane LED Status Table
Service LED
Green/Red
(on left)
Conc Out LED
Green/Amber
(on right)
Machine
Status
Resolution LCD Text
Normal Operation Solid Green Solid Green Normal
Operation
N/A
Concentrate Out Solid Green Flashing Amber Halt dispense
until concentrate
sensor is
satisfied
Change concentrate Affected side will
say “OUT”
Encoder Fail Solid Red Solid Green Halt dispense Remove pump, clean
& lube. Check for
plastic chad.
Rotometer Fail Solid Red Solid Green Halt dispense Check rotometer
counts. Clear error
through menu or
cycle power.
Motor High
Current
Solid Red Solid Green Halt dispense Remove pump, clean
& lube. Check for
plastic chad.
Teach Portion
Size
Flashing Green Solid Green Normal
dispensing
disabled. All
buttons manual
dispense to
teach various
sizes.
Exit Teach Mode (wait
for time-out).
See pg. 18.
Pump Head Lock
Not Found
Solid Green Solid Green Dispense
disabled
Lock pump head and
attempt another
dispense.
When dispense
tried, it will
momentarily say
Left Head Lock or
Right Head Lock.
Filter Not Installed Solid Green Solid Green Dispense
disabled
Install filter (display
will say “Filter
Installed”)
When dispense is
tried it will
momentarily say
“Install Filter”.
Initial Valve Purge
Mode
Alternating
Green/Red
Alternating
Green/Amber
Both water
valves on.
Remove shunt from
J4 or cycle power.
“Valves Purging”
