tbs electronics Omnicharge OCD12/12-50

Questions and Answers

K
Kaitlyn MurrayAug 1, 2025
What to do if my tbs electronics Battery Charger Omnicharge DC is not working?
- P
  Patricia MartinezAug 1, 2025
  If the Omnicharge DC is not working, there could be several reasons: * There may be no input voltage. In this case, check the wiring and input fuse. * The input voltage may be too low. Verify the input voltage, adjust the input voltage settings, or start the engine. * There might be no positive signal on the main On/Off control wire. Check the wiring, fuses, and the status of the engine run signal. * There could be a positive signal on the BMS input. Verify the output battery BMS status. * The input battery condition might be very poor, requiring a battery replacement.
M
Martin WoodardAug 6, 2025
Why is my tbs electronics Battery Charger not charging the battery to its maximum capacity?
- D
  Daniel BuckleyAug 6, 2025
  If the battery is not being charged to its maximum capacity, consider the following: * The absorption charge voltage setting may be incorrect. Check the battery type selection for the correct setting. * The charge current setting might be incorrect. Ensure the maximum output current setting is at the maximum level, verifying this is allowed by the battery manufacturer. * There could be too much voltage loss in the battery cables or connections. Ensure the battery cables have a sufficiently large diameter and that all DC connections are solid.
D
Danielle KelleyAug 10, 2025
What to do if battery load current is higher than tbs electronics Battery Charger output current?
- C
  Christina HortonAug 10, 2025
  If the battery load current is higher than the charger’s output current, reduce or remove the battery load.
K
Karen LeeAug 13, 2025
How to select the correct battery type on tbs electronics Battery Charger?
- E
  Elizabeth ChavezAug 14, 2025
  Select the correct battery type or adjust the charge voltage in the setup menu.
B
Brian ReevesAug 18, 2025
What to do if additional battery loads are consuming too much current during charging with tbs electronics Battery Charger?
- S
  Sara PinedaAug 18, 2025
  If additional battery loads are consuming too much current during charging, turn off or disconnect all battery loads.
E
emily32Aug 22, 2025
How to fix too thin DC cables on tbs electronics Battery Charger?
- A
  amanda44Aug 22, 2025
  Install larger DC cables.
J
John ClarkAug 27, 2025
What does it mean if my tbs electronics Battery Charger is operating in the absorption charging stage?
- M
  Mr. Joseph HallAug 27, 2025
  Do nothing. The battery is almost fully charged and consumes less current by itself.

Summary

Introduction

Intended Product Use

Describes the primary purpose of the Omnicharge DC battery chargers for charging auxiliary batteries from a vehicle starter battery.

Important Safety Information

Highlights critical safety precautions and warnings for using the Omnicharge DC battery charger, emphasizing reading all instructions.

Installation

Unpacking

Lists the items included in the Omnicharge DC charger package, such as the charger, grommets, sensor, manual, and terminals.

Mounting

Provides guidelines and diagrams for mounting the Omnicharge DC charger, including dimensions, screw spacing, and location considerations.

Wiring Details

Explains the correct DC wiring procedures for the Omnicharge DC charger, including safety warnings and connection order.

General Functionality

The Charging Process

Details the three-stage IUoUo charging process (Bulk, Absorption, Float) used by the Omnicharge DC charger for battery charging.

Charger Operation using the Main On;Off Control Input

Explains how to activate the charger using the main On/Off control input, including voltage and delay conditions.

Charger Operation without Using the Main On;Off Control Input

Describes how to operate the charger continuously by setting DIP switch 4 to ON, bypassing the On/Off control input.

LED Indicators

Explains the meaning of different LED states on the Omnicharge DC charger for input and output status.

Troubleshooting Guideline

Technical Specifications

Warranty Conditions

Declaration of Conformity
