TCF TCPE - Page 7

Twin City IM-4800 7
WALL COLLAR WITH ACCESSORIES — TCPE
Mounting Screw
Fan
Wall Collar
Backdraft Damper
Weatherhood
or
Damper
Guard
O
N
O
F
F
Variable
Speed Control
(Optional)
Disconnect Switch
(Optional)
O
F
F
O
N
Removable Screen
Panel Fan
OSHA Motor
Side Guard
Backdraft Damper
Weatherhood
Damper Guard
Bird Screen
Wall Collar
Disconnect
Switch
O
F
F
O
N
Removable Screen
Panel Fan
Wall Box
Backdraft Damper
Weatherhood
Bird Screen
Damper Guard
Disconnect
Switch
WALL COLLAR WITH ACCESSORIES — WPB, WPD
WALL BOX WITH ACCESSORIES — WPB, WPD
