TCL 10 TAB MAX User Manual

EN-7
6
Getting connected
To connect to the Internet with this tablet, you will need to have
an internet connection via Wi-Fi.
Wi-Fi
To turn Wi-Fi on and connect to a Wi-Fi network:
1. Go to Settings > Network& Internet > Wi-Fi.
2. Tap the switch
to turn on Wi-Fi.
3. Tap a Wi-Fi network to connect. If the network you selected
is a secured network, you will need to enter a password or
other credentials. When finished, tap CONNECT.
4. For hidden network, slide up the screen and select Add
network. Enter the SSID of the network, password and its
secured credentials. Then, tap SAVE.

TCL 10 TAB MAX Specifications

General

Device type	Mobile tablet
Form factor	Slate
Product color	Gray
Display diagonal	10.36 \
Touchscreen type	Capacitive
Display resolution	1200 x 2000 pixels
Native aspect ratio	15:9
Processor cores	8
Processor model	MT8788A
Processor family	Mediatek
Processor frequency	2 GHz
Processor manufacturer	MediaTek
Internal memory	4 GB
Storage media	-
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	256 GB
Internal storage capacity	64 GB
Number of microphones	2
Rear camera type	Single camera
Video capturing speed	30 fps
Video recording modes	1080p
Maximum video resolution	1920 x 1080 pixels
Rear camera aperture number	1.8
Resolution at capture speed	1920x1080@30fps
Rear camera resolution (numeric)	13 MP
Front camera resolution (numeric)	8 MP
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	5.0
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Mobile network connection	No
Headphone connectivity	3.5 mm
USB 2.0 Type-C ports quantity	1
Platform	Android
Operating system installed	Android 10
Battery capacity	8000 mAh
Extremities SAR (EU)	1.38 W/kg

Weight and Dimensions

Depth	157.56 mm
Width	247.8 mm
Height	7.65 mm
