TCL 21M62S User Manual

Con
fidential
TMPA8873
PSNG /
CMNG /CPNG /CRNG /CSNG
2005/03/29
31
Pin
No.
Pin Name Function Interface Circuit I/O Signal
28 Au out 1
Output terminal 1 for Audio
signal.
17
18
28
29 Au out 2
Output terminal 2 for Audio
signal.
17
40
29
30 TV out
Output terminal for detected
PIF signal.
17
18
30
31
1bit DAC
/SIF out
Output terminal for 1bit
DAC or detected SIF signal.
36
40
31
32 Ext Au2 in
Input terminal for Audio
signal 1.
17
32
18
35kΩ
35kΩ
5kΩ200Ω
33
H correc /
SIF in
Input terminal for H
correction and 2nd SIF.
33
36
40
500Ω
70kΩ
30pF
30kΩ
6pF
30kΩ
34 DC NF
Terminal to be connected
capacitor for DC Negative
Feedback from SIF Det
output.
34
17
18
500Ω
20kΩ
2kΩ
3kΩ
35 PIF PLL
Terminal to be connected
with loop filter for PIF PLL.
This terminal voltage is
controlled PIF VCO
frequency.
2kΩ15kΩ 500Ω
35
36
40
4kΩ
36 IF Vcc 5V
Vcc terminal for IF circuit.
Supply 5V.
⎯
