ASS PART NO. SEPC LOCATION
T8-HS36R3-M123 11-0BC337-0BX TRANSISTOR (NPN) BC337-40 Q1501
T8-HS36R3-M123 13-00AS12-13B IC AS1213B IC1501
T8-HS36R3-M123 14-IRE05B-XX0 IR EMITTING DIODE TSAL6200 D1501
T8-HS36R3-M123 18-CB0221-JNX RES. C.F. 220 OHM 1/6W +/-5% R1502
T8-HS36R3-M123 18-CB0229-JNX RES. C.F. 2.2 OHM 1/6W +/-5% R1501
T8-HS36R3-M123 25-HBB479-M1X CAP. ELEC 4.7 UF 10V +/-20% C1504
T8-HS36R3-M123 26-EBP101-JCS CAP. CER 100 PF 50V +/-5% C1501
T8-HS36R3-M123 26-EBP101-JCS CAP. CER 100 PF 50V +/-5% C1502
T8-HS36R3-M123 26-EBP104-ZFS CAP. CER 0.1UF 50V +80%/-20% C1503
T8-HS36R3-M123 40-UOCASR-RMB1XG P.C.B. REMOTE HANDSET BD
T8-HS36R3-M123 41-WJ0120-B00 WIREBAREJUMPER12MM J1501
T8-HS36R3-M123 45-COS455-KY1 CERAMIC RESONATOR 455KHZ X1501
T8-HS36R3-M123 49-HS36R1-00X9A RUBBER PAD KEYS
T8-HS36R3-M123 55-HS36RB-1HA5F LOWER CASE - REMOTE HANDSET
T8-HS36R3-M123 55-HS36RD-0HA5F BATT. DOOR - REMOTE HANDSET
T8-HS36R3-M123 55-HS36RT-1HAGG TV DEC AW UPPER CASE R=N
T8-HS36R3-M123 58-HS36R3-1UI9C INLAY REMOTE HANDSET
T8-HS36R3-M123 67-X38064-0E2 BATTERY SPRING (+/-)
T8-HS36R3-M123 67-X38065-0E2 BATTERY SPRING (+)
T8-HS36R3-M123 67-X38066-0E2 BATTERY SPRING (-)
T8-HS36R3-M123 74-007026-60C POLYBAG (70MMX260MMX0.06MM)
T8-0021GPS-MA1 10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) D301
T8-0021GPS-MA1 10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) D404
T8-0021GPS-MA1 10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) D401
T8-0021GPS-MA1 10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) D402
T8-0021GPS-MA1 10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) D406
T8-0021GPS-MA1 10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) D409
T8-0021GPS-MA1 10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) D403
T8-0021GPS-MA1 10-1N4002-EBX DIODE 1N4002 (RECTIFIER) D425
T8-0021GPS-MA1 10-1N4002-EBX DIODE 1N4002 (RECTIFIER) D424
T8-0021GPS-MA1 10-1N4002-EBX DIODE 1N4002 (RECTIFIER) D405
T8-0021GPS-MA1 10-1N4148-ABX DIODE 1N4148 (SWITCHING) D206
T8-0021GPS-MA1 10-1N4148-ABX DIODE 1N4148 (SWITCHING) D012
T8-0021GPS-MA1 10-1N4148-ABX DIODE 1N4148 (SWITCHING) D002
T8-0021GPS-MA1 10-1N4148-ABX DIODE 1N4148 (SWITCHING) D303
T8-0021GPS-MA1 10-1N4148-ABX DIODE 1N4148 (SWITCHING) D302
T8-0021GPS-MA1 10-1N4148-ABX DIODE 1N4148 (SWITCHING) D305
T8-0021GPS-MA1 10-1N4148-ABX DIODE 1N4148 (SWITCHING) D307
T8-0021GPS-MA1 10-1N4148-ABX DIODE 1N4148 (SWITCHING) D413
T8-0021GPS-MA1 10-1N4148-ABX DIODE 1N4148 (SWITCHING) D616
T8-0021GPS-MA1 10-1N4148-ABX DIODE 1N4148 (SWITCHING) D615
T8-0021GPS-MA1 10-79C33V-DBX DIODE ZENER 33V 1/2W 5% D101
T8-0021GPS-MA1 10-79C3V9-DBX DIODE ZENER 3V9 1/2W 5% D411
T8-0021GPS-MA1 10-79C3V9-DBX DIODE ZENER 3V9 1/2W 5% D304
T8-0021GPS-MA1 10-HS5V1B-DBX DIODE 500MW 5.1HSB D216
T8-0021GPS-MA1 11-KTD863-0BX TRANSISTOR KTD863 Q401
T8-0021GPS-MA1 11-SA1015-YBX TRANSISTOR ST2SA1015Y (PNP) Q616
B - PAL M/N NTSC-M AV.ST/RCA-2/S.AV IN/Y03-DM62SGP-BO23S
