TCL 21M62S User Manual

TCL-Thomson Electronics R D Center (Shen’Zhen Lab)
Model
机型
Item
内容
-Number of Local Control(incl.Mains)
-本机控制按键孔数量(包括主开关)
7
-Number of Indicator Control(incl.Mains)
-本机指示灯数量(包括主开关上的灯)
1
Local Controls Front
-正面的控制孔数量
-Mains Switch
电源开关
X
-CH+ CH- VOL+ VOL-
频道+-，音量+-
-TV/AV
TV / AV
-Menu
菜单
-Auto Search
自动搜台
Local Controls Top
-顶部的控制孔数量
-CH+ CH- VOL+ VOL-
频道+-，音量+-
X
-TV/AV
TV / AV X
-Menu
菜单
X
-Auto Search
自动搜台
Local Controls Side
-侧面的控制孔数量
-CH+ CH- VOL+ VOL-
频道+-，音量+-
-TV/AV
TV / AV
-Menu
菜单
-Auto Search
自动搜台
Indicator
-指示灯
-RC Received LED
遥控接收灯
-Color of RC Received LED
遥控接收灯颜色
-Standby LED
待机灯
X
-Color of Standby LED
待机灯颜色
RED
Remote Controller
遥控器
-Type
-类型
R
-Batteries Type
-电池
2XAA
Connectors Rear
后壳端子接口
-SCART Full (RGB) w/o Y/C
不含Y/C的SCART
-SCART Full with Y/C
含Y/C的SCART
-SCART Single (CVBS)
-单SCART接口(CVBS)
-Component In (YCbCr) Cinch
YUV
X
-In Y/C+Cinch(CVBS+ Stereo) -In Y/C+Cinch(CVBS+ Stereo)
X
-In Y/C+Cinch (CVBS+ Mono) -In Y/C+Cinch (CVBS+ Mono)
-In Cinch(CVBS+ Stereo) -In Cinch(CVBS+ Stereo)
X
-In Cinch (CVBS+ Mono) -In Cinch (CVBS+ Mono)
-Out Cinch(CVBS+ Stereo) -Out Cinch(CVBS+ Stereo)
X
-Out Cinch(CVBS+ Mono) -Out Cinch(CVBS+ Mono)
-Super Woofer
-超重低音接口
-Digital Audio Out
-数字音频输出
-Loudspeakers
-外接喇叭口
-Control Busses
-控制总线
-After Service Slot
-售后维修口
-ITV Smart Port
-ITV 通信端口
- Antenna in
-天线输入端口
75 Ohms (IEC Type)
75 ohms (IEC类型）
X
Connectors Front
正面端子接口
-In Y/C+Cinch(CVBS+ Stereo) -In Y/C+Cinch(CVBS+ Stereo)
-In Y/C+Cinch (CVBS+ Mono) -In Y/C+Cinch (CVBS+ Mono)
-In Cinch(CVBS+ Stereo) -In Cinch(CVBS+ Stereo)
-In Cinch (CVBS+ Mono) -In Cinch (CVBS+ Mono)
-Out Headphone
-耳机输出端口
Mini-Jack 3.5mm
袖珍插孔 3.5mm
Connectors Side
侧面端子接口
-In Y/C+Cinch(CVBS+ Stereo) -In Y/C+Cinch(CVBS+ Stereo)
-In Y/C+Cinch (CVBS+ Mono) -In Y/C+Cinch (CVBS+ Mono)
-In Cinch(CVBS+ Stereo) -In Cinch(CVBS+ Stereo)
X
-In Cinch (CVBS+ Mono) -In Cinch (CVBS+ Mono)
-Out Headphone
-耳机输出端口
Mini-Jack 3.5mm
袖珍插孔 3.5mm
Final Equipment
出厂资料
-Packing –Methods
-包装方法
* Colors Printing
几种颜色彩印
Chassis: M123SP(南美)
Page: 3 of 7
