Item No. Description Quantity Req. Designator Remarks

41-WJ0165-B00 WIRE BARE JUMPER 16.5MM 1 J029

41-WJ0165-B00 WIRE BARE JUMPER 16.5MM 1 J225

41-WJ0175-B00 WIRE BARE JUMPER 17.5MM 1 J915

41-WJ0185-B00 WIRE BARE JUMPER 18.5MM 1 J015

41-WJ0185-B00 WIRE BARE JUMPER 18.5MM 1 J606

41-WJ0190-B00 WIRE BARE JUMPER 19MM 1 J926

41-WJ0190-B00 WIRE BARE JUMPER 19MM 1 J914

41-WJ0190-B00 WIRE BARE JUMPER 19MM 1 J913

41-WJ0190-B00 WIRE BARE JUMPER 19MM 1 J218

41-WJ0200-B00 WIRE BARE JUMPER 20MM 1 J010

41-WJ0200-B00 WIRE BARE JUMPER 20MM 1 J011

41-WJ0200-B00 WIRE BARE JUMPER 20MM 1 J012

41-WJ0200-B00 WIRE BARE JUMPER 20MM 1 J013

41-WJ0200-B00 WIRE BARE JUMPER 20MM 1 J014

41-WJ0200-B00 WIRE BARE JUMPER 20MM 1 J211

41-WJ0200-B00 WIRE BARE JUMPER 20MM 1 J215

41-WJ0200-B00 WIRE BARE JUMPER 20MM 1 J216

41-WJ0200-B00 WIRE BARE JUMPER 20MM 1 J217

41-WJ0200-B00 WIRE BARE JUMPER 20MM 1 J230

41-WJ0200-B00 WIRE BARE JUMPER 20MM 1 J604

45-OSC8M0-0Y0 CRYSTAL 8.0MHZ 1 X001

45-TRA4M5-0Y0 CER TRAP TPS 4.5MHZ 1 X201

46-20598W-04X PIN BASE *4 TJC1-4A 1 P411 FOR D.Y CONNECTOR

46-33079W-03X PIN BASE *3 TJC3-3A 1 P002 P2 - P4 FOR W. BAL ADJUST

46-37030H-05X HS 5P 2468#24 450 TJC3-5Y/SCN 1 P201 P1 - P5 FOR CRT BD P503

57-10654X-00F cable ties(2.5mmX95mm) 3

62-227680-0UA BRACKET ABS-KINGFA 606 (UO) 1

64-P30080-104 M/C SCREW P 3 X 8 1 FOR IC301

64-P30080-104 M/C SCREW P 3 X 8 1 FOR Q411

64-P30080-104 M/C SCREW P 3 X 8 1 FOR Q414

64-P30100-104 M/C SCREW P 3 X 10 2 FOR IC602

65-Z30050-23M NUT M 3 2 FOR IC301 & Q411

66-343730-0B0 HOLLOW RIVET 1.6X3.0XL3.2 3 FOR C411(1,2,3)

66-343730-0B0 HOLLOW RIVET 1.6X3.0XL3.2 10 FOR T402(1,2,4,5,6,7,8,9,10,11)

66-343730-0B0 HOLLOW RIVET 1.6X3.0XL3.2 3 FOR C414(1,2,3)

21
