TCL 32DD420 User Manual

EN
11
English
Using more of your TV
Customising the input settings
You can configure your TV according to the
equipment you connect to it.
1. Press Menu on the remote control, select
Settings > System > Input settings and press
OK/► to enter.
2. Press ▲/▼ to select a connector your equipment
is connected to, press OK/► to enter.
3. Press ▲/▼ to select the type of apparatus
attached to this connector, and press OK to
conrm.
4. Press Exit to close the menu.
After configuring, the selected source label will be
displayed after the name of the related connector in
the input source list when pressing Source on the
remote control or in the main menu when pressing
Menu on the remote control.
Changing to shop or home mode
1. Press Menu on the remote control, select
Settings > System > Location and press OK/►
to enter.
2. Press ▲/▼ to select your location Shop or Home,
and press OK to conrm.
3. Press Exit to close the menu.
Note: According to the regulation of European
Commission 2009/125/EC, in Home
mode, TV will be put into standby mode
automatically if there is no operation in
4 hours. Select Settings > Time > Auto
Standby to deactivate this feature.
Software update
Use this function to update the software.
1. Press Menu on the remote control, select
Settings > System > Software update and press
OK/► to enter.
2. Press ▲/▼ to select your desired way to update
the software and press OK/► to start.
Reset shop
Allows you to reset the TV to factory default settings.
1. Press Menu on the remote control, select
Settings > System > Reset shop and press OK
to enter.
2. Use the numeric buttons to enter the password.
3. Press ◄/► to select OK and press OK to start.
4. The Hello screen appears. Follow the on-screen
instructions.
Viewing pictures, playing music and
watching movies from a USB storage
device
Your TV is fitted with USB connectors that enable you
to view photos, listen to music or watch videos stored
on a USB drive.
Supported file formats:
Picture JPEG, PNG, BMP, GIF.
Music MP3
Movie H.265, H.264, MPEG1/2/4, VC1, AC3,
AAC, HEAAC, LPCM.
Notes:
- Some USB keys and USB products like
digital cameras or mobile phones are not fully
compatible with USB 2.0 standard so they may
not work with the TV multimedia player. Not
all USB keys or devices are compatible with
the USB function. Not all above formats are
recognised. The encoding formats of your les
will determine whether or not they can be used.
- Format H.265 may not be available for certain
models.
To enter the Media menu, press Source on the
remote control and select Media.
Use this function to display photos, if available.
1. Select Media > Picture, then press OK to enter.
2. After selecting the proper disk, press OK to enter,
then use ▲/▼/◄/► to select a photo.
3. Press OK to watch, a slide show begins from the
selected photo. Press OK to pause. Press Menu
to display the photo menu. You can play, pause or
rotate the photo, select different play modes and
display effects, etc.
Music
Use this function to play music, if available.
1. Select Media > Music, then press OK to enter.
2. After selecting the proper disk, press OK to enter,
then use ▲/▼/◄/► to select a song.
3. Press OK to play, and automatic playback begins
from the selected song. Press Menu to display
the music menu. You can play or pause the song,
select different play modes, etc.
Movie
Use this function to watch videos, if available.
1. Select Media > Movie, then press OK to enter.
2. After selecting the proper disk, press OK to enter,
then use ▲/▼/◄/► to select a video.
3. Press OK to watch, and automatic playback
begins from the selected video. Press Menu to

TCL 32DD420 Specifications

General

Screen shape	Flat
Response time	30 ms
Display diagonal	32 \
Display brightness	240 cd/m²
Display resolution	1366 x 768 pixels
Display technology	LCD
Native aspect ratio	16:9
Native refresh rate	60 Hz
Peak luminance ratio	80 %
LED backlighting type	Direct-LED
Supported video modes	768p
Viewable size diagonal	800 mm
Contrast ratio (typical)	-
Display diagonal (metric)	81.3 cm
Motion interpolation technology	PPI (Picture Performance Index) 100
Dynamic contrast ratio marketing name	Mega Contrast
HDMI version	1.4
PC in (D-Sub)	No
RF connector type	F, IEC
USB 2.0 ports quantity	1
Common interface Plus (CI+)	Yes
Common interface Plus (CI+) version	1.3
Tuner type	Analog & digital
Analog signal format system	NTSC, PAL, SECAM
Digital signal format system	DVB-C, DVB-S2, DVB-T2
Audio formats supported	MP3
Image formats supported	BMP, JPG, PNG
Video formats supported	AVI, MKV, MP4, MPG, OGM, TS
Picture processing technology	TCL Pure Image
Programming period	8 day(s)
Number of OSD languages	30
Firmware upgradeable via	USB
On Screen Display (OSD) languages	ALB, BOS, BUL, CRO, CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, LAT, LIT, MAC, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, TUR, UKR
Cables included	AC
Remote control type	RC300
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	55 W
Power consumption (standby)	0.22 W
Power consumption (typical)	31 W
Package type	Box
Package depth	126 mm
Package height	512 mm
Package weight	5300 g
Audio decoders	Dolby Digital, Dolby Digital Plus
RMS rated power	10 W
Product color	Black
Mercury content	0 mg
Heavy metals free	Hg (mercury)
Panel mounting interface	100 x 100 mm
Certification	CE
Battery type	AAA
Battery weight	15 g
Battery technology	Alkaline
Truck type	87 cbm
Pallet width	1200 mm
Pallet height	1164 mm
Pallet weight	107900 g
Pallet net weight	12500 g
Quantity per truck	1188 pc(s)
Quantity per pallet	18 pc(s)
Number of pallets per truck	66 pc(s)
Maximum number of stacking cartons	5 pc(s)
Repairability index	6.4

Weight and Dimensions

Stand width	615 mm
Depth (with stand)	175 mm
Height (with stand)	480 mm
Weight (with stand)	4000 g
Depth (without stand)	80 mm
Width (without stand)	732 mm
Height (without stand)	435 mm
Weight (without stand)	3900 g
