Page #31 background imageLoading...
Page #31 background image
59 60
Developer options
To enable this function, go to Settings > System > About phone, then touch
Build number 7 times. Now Developer options is available. The developer
options contain settings that are useful for developing Android applications.
Reset
Touch to reset all network settings and app preferences, you won't lose your data
with these settings.
If Factory data reset is selected, all data in your phone's internal storage will be
erased, please back up your data before reset.
Regulatory & safety
Touch to view product information such as Product model, Manufacturer name,
Manufacturer address, IMEI, CU reference, Bluetooth Declaration ID, etc.
User Experience Improvement Programme
Touch to join the User Experience Improvement Programme so we can continue
to improve our product design and overall user experience.
5
Making the most of your phone
FOTA upgrade
Use the FOTA (Firmware Over The Air) upgrade to update your phone's software.
To access updates, from the app list, touch Settings > System > System Update.
Turn on data connection or Wi-Fi before searching for updates.
With Wi-Fi turned on, the system is able to discover if a new firmware version is
available and if so, begin to download it automatically. Once finished, a pop up
dialog will give you the option of updating your phone now or later.
If Settings > System > System Update > > Update settings > Automatically
update is turned off, you will only receive a notification which will appear in the
Status bar.
During FOTA downloading or updating, to avoid errors in locating the correct
update packages, do not change your default storage location.
After FOTA update compeletly, it need restart device, it will prompt tips to restart
device

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TCL 40R 5G and is the answer not in the manual?

TCL 40R 5G Specifications

General IconGeneral
Color nameStarlight Black
Form factorBar
Product colorBlack
Housing materialPlastic
User memory44 GB
RAM capacity4 GB
Memory card slot typeHybrid slot
Compatible memory cardsMicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size1000 GB
Internal storage capacity64 GB
Screen shapeFlat
Pixel density269 ppi
Display diagonal6.6 \
Display brightness400 cd/m²
Display resolution720 x 1612 pixels
Native aspect ratio20:9
Maximum refresh rate90 Hz
Rounded display cornersYes
Contrast ratio (typical)1200:1
Talk time (3G)- h
Battery voltage5 V
Battery capacity5000 mAh
Battery recharge time3 h
Subscription typeNo subscription
USB version2.0
USB connector typeUSB Type-C
Headphone connectivity3.5 mm
Rear camera typeTriple camera
Front camera typeSingle camera
Maximum frame rate30 fps
3D depth front cameraNo
Rear camera pixel size0.64 µm
Front camera pixel size1.12 µm
Rear camera sensor size1/2.76 \
Front camera sensor size1/4 \
Macro camera sensor size0.2 \
Rear camera lens elements5-element lens
Rear camera aperture number1.8
Front camera aperture number2
Second rear camera pixel size1.75 µm
Video capture resolution (max)1920 x 1080 pixels
Rear camera resolution (numeric)50 MP
Second rear camera lens elements3-element lens
Front camera resolution (numeric)8 MP
Macro camera resolution (numeric)2 MP
Second rear camera aperture number2.4
Rear camera field of view (FOV) angle74.2 °
Front camera field of view (FOV) angle80.6 °
Third rear camera field of view (FOV) angle88.8 °
Second rear camera field of view (FOV) angle85 °
SpeakersMono
Audio formats supportedAAC, ADPCM, AMR-NB, AMR-WB, APE, FLAC, MIDI, MP3, Vorbis, WAV
Video formats supportedH.264, HEVC, MPEG4, VP8, VP9
4G standard-
3G standardsHSPA+
SIM card typeNanoSIM
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version5.1
SIM card capabilityHybrid Dual SIM
Mobile network generation5G
Processor cores8
Processor model700
Processor familyMediaTek Dimensity
Processor frequency2.2 GHz
Processor architectureARM Cortex-A76+Cortex-A55
Graphics cardMali-G57 MC2
Country of originChina
PlatformAndroid
Operating system installedAndroid 12
Weight and Dimensions IconWeight and Dimensions
Depth8.99 mm
Width75.4 mm
Height164.46 mm
Weight192 g
Package depth59 mm
Package width172 mm
Package height50 mm
Package weight342.4 g
