TCL 40XE 5G User Manual

13
Swipe to unlock the screen
Press the Power key once to light up the screen. Swipe up the screen to unlock
the screen.
(1)
Swipe right to
enter Phone
(1)
Swipe left to
enter Camera
(1)
Swipe up to
unlock the screen
Enter a password to unlock the screen
Once the screen is turned on, swipe up the screen to display the password input
panel. Then enter your lock screen password.
Use pattern unlock
Draw the same pattern you have set to unlock the screen.
Use Face unlock
• From the app list, tap Settings > Security & biometrics > Face unlock. Before
using the face unlock, you need to set a pattern/PIN/password.
• Hold your phone 20-50 cm from your face. Position your face in the square
shown on the screen. For best results, we suggest that the face key is enrolled
indoors and away from direct sunlight.
• Enable Face unlock when your screen turns on, otherwise you will have to swipe
up on the screen first of all.
(1)
Customized by tapping Settings > Home screen & lock screen > Lock screen
shortcut.

TCL 40XE 5G Specifications

General

Display Size	6.56 inches
Resolution	720 x 1612 pixels
Processor	MediaTek Dimensity 700
RAM	4GB
Storage	64GB
Front Camera	8 MP
Battery Capacity	5000 mAh
Operating System	Android 13
Network Technology	GSM / HSPA / LTE / 5G
Status	Available
Build	Glass front, plastic frame, plastic back
SIM	Nano-SIM
Type	IPS LCD
CPU	Octa-core (2x2.2 GHz Cortex-A76 & 6x2.0 GHz Cortex-A55)
GPU	Mali-G57 MC2
Main Camera Features	LED flash, HDR, panorama
Main Camera Video	1080p@30fps
Selfie Camera Video	1080p@30fps
Loudspeaker	Yes
3.5mm jack	Yes
Bluetooth	5.1, A2DP, LE
Positioning	GPS, GLONASS, GALILEO, BDS
NFC	No
Radio	FM radio
USB	USB Type-C 2.0
Sensors	Fingerprint (side-mounted), accelerometer, proximity, compass
Charging	18W wired
Rear Camera	2 MP
Announced	2023
Chipset	MediaTek MT6833 Dimensity 700
WLAN	Wi-Fi 802.11 a/b/g/n/ac, dual-band
Colors	Black
Dimensions	164.5 x 75.2 x 8.9 mm (6.48 x 2.96 x 0.35 in)
