Optional - To mount on a wall
(wall mount not included)
Preparation must be done before mounting your TV on a wall.
To mount on a wall
1
Place your TV on a soft, cushioned surface.
2
3 4
The VESA number is the horizontal and vertical measurement of the mounting holes. For
example, 200X200 refers to the fact that the mounting measurements are 200mm horizontally
and 200mm vertically.
Follow the instructions that come with the wall mount.
Your wall mount must be able to bear a minimum of five times the TV’s net weight to avoid
causing damage.
Purchase a VESA 200x200 (4 M6x12mm screws)
If you are mounting your TV to the wall, don’t attach the stands.
To mount your TV to the wall, purchase a VESA wall mount
Models of 55’’
Models of 65’’ Purchase a VESA 200x200 (4 M6x12mm screws)
Remove the 2 screws on the back of the TV.
Screw the VESA bracket tightly onto the
back cover with 4 VESA screws.
Follow the instructions that come with the
wall mount to hang the TV on the wall.
6
Note: 1. If you select wall mounting, you should connect to the Ethernet which placed on the
2. Do not place your TV in a location exposed to direct sunlight, heat, fire, or moisture.
Exposure will damage the TV.
Warning: This product should only be mounted by a professional installer.
Warning: Never install or mount this product to the ceiling with the screen side facing down.
Installing or mounting this product to the ceiling or the underside of a structure or surface is
hazardous and may result in personal injury and/or property damage.
back of the TV before mounting your TV on a wall.
