Item No. Description Quantity Req. Designator Remarks
27-RCP333-J0X CAP. PP 0.033 UF 100V +/-5% 1 C405
13-L7805C-VAP IC L7805CV 1.5A (REGULATOR) 1 IC402
27-MBC103-J0X CAP. M.P.E 0.01UF 63V+/-5% 1 C215
27-PBC472-J0X CAP. P.E 0.0047UF 63V +/-5% 1 C607
27-PBC472-J0X CAP. P.E 0.0047UF 63V +/-5% 1 C608
18-CB0220-JNX RES. C.F. 22 OHM 1/6W +/-5% 1 R001
18-CB0220-JNX RES. C.F. 22 OHM 1/6W +/-5% 1 R005
18-CB0472-JNX RES. C.F. 4.7k OHM 1/6W +/-5% 1 R003
18-CB0472-JNX RES. C.F. 4.7k OHM 1/6W +/-5% 1 R004
34-A220K0-1IX COIL PL - 22UH +/-10% LGA0305-220K 1 L201
66-343740-0B0 HOLLOW RIVET (2.3mmx4.0mmx3.5mm) 2 FOR R402
41-WJ0055-B00 WIRE BARE JUMPER 5.5 MM 1 J922
46-33079W-03X PIN BASE *3 TJC3-3A 1 P001
18-FF0102-JGX RES. M.O. 1k OHM 1W +/-5% 1 R408
27-PBC472-J0X CAP. P.E 0.0047UF 63V +/-5% 1 C422
10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) 1 D404
18-FF0123-JGX RES. M.O. 12k OHM 1W +/-5% 1 R406
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 J305
40-2111SG-MAI1X P.C.B. MAIN PCB BD 1
41-WJ0105-B00 WIRE BARE JUMPER 10.5MM 1 R406A
41-WJ0085-B00 WIRE BARE JUMPER 8.5MM 1 J205
41-WJ0085-B00 WIRE BARE JUMPER 8.5MM 1 J206
25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20% 1 C900
10-79C8V2-DBX DIODE ZENER 8V2 1/2W 5% 1 D406
26-EBP470-JZX CAP. CER 47PF 50V +/-5% SL 1 C424
26-EBP222-KBX CAP. CER 2200PF 50V +/-10% B 1 C014
41-WJ0150-B00 WIRE BARE JUMPER 15MM 1 L402
41-WJ0070-B00 WIRE BARE JUMPER 7MM 1 J223
26-EBP101-JZX CAP. CER 100pF 50V +/-5% SL 1 C001
26-EBP101-JZX CAP. CER 100pF 50V +/-5% SL 1 C002
26-EBP390-JZX CAP. CER 39 pF 50V +/-5% 1 C021
26-EBP390-JZX CAP. CER 39 pF 50V +/-5% 1 C022
08-0A21SG-PWY 1
10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) 1 D833
10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) 1 D802
19
