TCL AT2127 User Manual

Bit 7
Bit 0
America V-CHIP standard 1：yes 0：no
Bit 1
Canadian V-CHIP 1：yes 0：no
Bit 2
UNRATED，1：yes 0：no
Bit 3
NO RATING，1：yes 0：no
MDOE8
Bit 4
~Bit 7
Time setting for curtain when turn on the set
Bit 0
~Bit 2
N/A
Bit 3
S-VIDEO ,0:parallel to AV1 1: parallel to AV2
Bit 4
1:sound effect w/o mpx (MSP3465)
MDOE9
Bit 5
~Bit 7
N/A
Menu 12(Remote key: “CAP”)
Item
Remark
OSD2 OSD Horizontal Position
OSDF2 OSD PLL DATA except
PYNX Normal H.SYNC max
PYNN Normal H.SYNC min
PYXS Search H.SYNC max
PYNS Search H.SYNC min
Menu 13 (Remote key: “Display” )
Item
Remark
CLTM
TV mode
CLVO Video mode
CLVS s-video mode
Bit 2 ~ 0 YDL [15H, bit 2 ~ 0] (-40ns~240ns)
Bit 4 ~ 3 NTSC matrix [03H, bit 7 ~ 6] (N1,N2,DVD)
Bit 5 C gamma [02H, bit 7] (color gamma on/off)
Bit 6 P/N ID [17H, bit 4] (PAL/NTSC killer sensit.)
Bit 7 FID [17H, bit 3] (Killer off)
Bit 1 ~ 0
ABL gain [16H, bit 5 ~ 4]
Bit 3 ~ 2 ABL start point [16H, bit 7 ~ 6]
Bit 4 WPS [00H, bit 7]
ABL
Bit 5 OSD ABCL [16H, bit 3]
Bit 1 ~ 0 Black stretch [15H, bit 4 ~ 3]
Bit 3 ~ 2 Y gamma [15H, bit 6 ~ 5]
Bit 5 ~ 4 OSD level [16H, bit 1 ~ 0]
DCBS
Bit 7 Blank switch [0CH, bit 7]
Bit 0
Over modulation [13H, bit 5]
Bit 1
Aft window size [13H, bit 6]
Bit 2
Buzz reducer [13H, bit 7]
Bit 3 Audio gain switch [14H, bit 7]
Bit 4
Bit 5
Bit 6
FLG0
Bit 7
1: VCO adjust automatically when changing
channel
Bit 0
CW SW [06H, bit 7], control PIN26,
Bit 1
Slice level [1EH, bit 6]
Bit 2
Mix gain [15H, bit 7]
FLG1
Bit 3
V ramp bias [1DH, bit 4]
