6
Let’s Get Started!
Installation & Assembly Instructions for: D Series
Step 1: Testing
• Do not use outdoors.
• Place the unit on a smooth level surface.
• Allow at least 12 -18 inches of clearance on all sides of the unit.
• Place the unit in a space where the temperature will not fall below 41 degrees Fahrenheit.
• The dehumidifier must be operated in an enclosed area to be most eective, such as a basement.
• Close all doors, windows, and other outside openings to the room.
Step 2: Installation
There are two sizes of cabinet
Smaller cabinet size (WxHxD) Bigger cabinet size (WxHxD)
370mm x 505mm x 270mm
14.57in x 19.88in x 10.63in
382mm x 640mm x 305mm
15.04in x 25.20in x 12.01in
For the smaller cabinet:
Before use, please remove the accessories from the bucket
1a. Remove the bucket from appliance.
1b. Open the cover, take out the accessories. (Fig 1ab).
1c. Reinstall the cover, correctly put the bucket back into the appliance (Fig 1c).
1ab. 1c.
1a. 1b. 1c. 1d.
Wheels and other
accessories
Wheels
Latches
For the bigger cabinet:
Before use, please remove the accessories from the bucket
1a. Remove the bucket from appliance. Note: Not all models have handles (Fig 1a).
1b. Make sure to release the cover by pushing in the two latches at the top of the bucket(Fig 1b).
1c. Open the cover, take out the accessories. (Fig 1c).
1d. Reinstall the cover, correctly put the bucket back into the appliance (Fig 1d).
1a. 1b. 1c. 1d.
Wheels and other
accessories
Latches
