Factory Test & Alignment Specification For MS63F-LA Series (V0.10)
Page 8 of 18
Press RCU “Exit” key exit the Factory menu.
Factory Captions Info.
While “FactoryKey” is enabled, there’re some toggled display informations relative to SW,
ProjectID, ADC Status, to facilitate 100% quick screening without accessing to whatever else
menu:
Î Mboot SW Version
Î Main SW Version
Î Project ID
Î P (Production/Factory mode flag) / S (Factory UART
Parser mode flag) / W (Warm-Up mode flag)
See Appendix
“Factory Menu Description”
2.2. Warm-up Test
Following TCL standard and practices, it’s required minimum 15min of Warm-Up that can be
considered as Burn-In.
Additional Aging for White Balance alignment is no more necessary due to consistent Picture
Performance with Cloning usage.
This function is accessible by selecting “Factory menu
WARM-UP”, pressing RCU “Zoom+”
key and then leaving Factory menu. Other faster methods are available on above enclosed
SIACP requirements (rev. v3.9).
2.3. White Balance (WB)
White Balance Touch-Up
As some color coordinates discrepancies can be noticed from panel batches to others, it may
necessary to perform slight touch-up.
For Color temperature adjustment, switch TV on leading HDMI input where should be connected
suitable generator providing following format 1280x720p@60Hz test pattern. A 32 steps grey scale is
recommended to assess relevant colorimetry tracking and low/high light saturation points.
