Factory Test & Alignment Specification For MS63F-LA Series (V0.10)
Page 5 of 18
In case of starting from blanked flash, it’s necessary to write first “V8-6328L01-LB1Rxxx” file.
Then, following files need to be written down:
- “MS6328LA_FULL_UPGRADE.bin”
See Appendix n “How to upgrade FLASH SW using Mstar tool”
See Appendix
o “How to upgrade FLASH SW using USB”
1.3. Project ID Modification
There are different IDs stored into the NVM depending on different Panels settings and Models
features, but there’s only one key branching ProjectID that includes all. So, it’s not recommended to
modify Panel ID with Hyper terminal as other ID features may not change!
To modify Project ID, you need to go through “Design menu
Service menu
Project ID”, then
spin left or right with RCU “Zoom±” keys to suitable ID (Project name is dynamically refreshed).
See Appendix
p “How to change Project ID with RCU”
Here below is none exhaustive ProjectID table for reference:
MODEL
ProjectID Panel Name
L32E5300 001
L46E5300F 002
L42E5300F 003
L42D4330F3D 004
L39E5300F/CMI 005
L39E5300F/AUO… 006…
1.4. Functional Test
Once the boards (chassis, KB, IR, PSU…) and the panel are well interconnected, plug all
external generator devices to relevant inputs/outputs below according to their respective test patterns
format and check picture content and sound quality accordingly:
Source Test Signal Test Pattern
Analog /Digital Tuner
(VHF/UHF & CATV)
RF cable generator
2D - Movie 1280x720
2D - Static Picture 1920x1080
1. Frequency Range: full band
2. Standard: NTSC /PAL M
3. ISDB-T
SPDIF (optical)
Audio Amplifier PCM or Dolby D+
AV 1 IN
(CVBS & AUDIO)
Chroma/Fluke
generator
PAL Half Color & Gray bars
AV 2 IN
(CVBS &AUDIO)
Chroma/Fluke
generator
PAL Half Color & Gray bars 720x576
Half Color & Gray bars
VGA
Chroma/QuantumData UXGA - 1600x1200@60Hz
