Factory Test & Alignment Specification For MS63F-LA Series (V0.10)
Page 6 of 18
(VGA&AUDIO) generator Half Color & Gray bars
CMP via mini jack adaptor
(YPrPb & Audio)
Chroma/QuantumData
generator
1920x1080i@60Hz
Half Color & Gray bars
HDMI
(Video & Audio)
with beyond HDMI 1.3
and HDCP compliant
DVD/BD player
2D - Movie 1280x720i@60Hz
3D - Movie 1920x1080@p24Hz
RJ45
(LAN)
DHCP Server ICMP packets echo request
Headphone via mini jack adapter
RF signal Suitable channel
Loud Speakers / Enclosures
RF signal Suitable channel
AV OUT
(Video & Audio)
RF signal Suitable channel
Audio tones can be defined by the factory (ie: 1KHz & 3KHz, sweep, …).
Picture video formats can be changed by the factory according to their own standard.
Remark˖1.CMP Audio in shared with AV1.
2.VGA Audio in shared with AV2.
1.5. AD Calibration Test
As SoC as built-in A/D self-calibration mechanism, there’s not any ADC to perform.
1.6. DDC & EDID & T-Link Test
The E-EDID data structures are according to VESA Enhanced EDID 1.3 (and EIA/CEA-861B for
HDMI). CEA Timing Extension structure has been extended to support all 3D capable timings.
All VGA and HDMI structures have their own BIN profile which are part of main SW and uploaded
at power-on into HDMI switch chipset:
For EDID check, it’s needed to check whether the correct EDID is downloaded by checking
corresponding EDID NVM Checksum or read them out to check bit by bit if it is in line with the
released EDID bin file.
1.7. HDCP Test
For HDCP compliancy, it’s needed to check whether the HDCP key has been well set.
1.8. LAN/WLAN Test (MAC address and Device/User ID codes)
MAC Address Upgrade
See Appendix s“How to upgrade MAC Address
DeviceID (DID) and UserID (UID)
Purpose is to allow Other Newtork Download (OND) and further specific Services over dedicated
portal based on UK.
Description/Portal Links/Flow chart are welcome ?
For such, specific DID (32 bytes) and UID (8 bytes) needs to be paired and overwritten into
