EM BUSINESS CENTER
FTV PRODUCT PLANNING DEPT.
SPECIFICATION RELEASE
Version: V1.0 Issued Date: 2014.02.24 Page 1 of 1
Panel Size (inch)
55inch
Category
LCD TV(DIRECT LED)
Aspect Ratio 16:9
Color Temperature Warm / Normal/ Cool /Customer
Backlight Adjustable
Yes SIGNAL FORMAT CAPABILITY
Scaler Mode
16:9 format,4:3 format,Cinerama,16:9 zoom,16:9 zoom up
Component Video Format Y,Pb,Pr:up to 720p,1080i,1080p @50Hz/60Hz
Picture Effect 5 picture effects preset(Personal,Movie,Standard,Dynamic,Studio) DVI Video Format Up to1920*1080@60Hz
Film Mode (3:2 pull down)
AUTO ON/OFF HDMI Video Format Up to 720p,1080i,1080P
Picture Enhancement PC Compatibility VGA: up to UXGA@60Hz
Comb Filter
3D TERMINALS
Audio/CVBS Input (Composite)
1R/L+1Video(share with YPbPr )
YPbPr Input
1(RCA)
MPEG NR
yes Audio Input for YPbPr
1R/L
MDDi
TM
yes YPbPr Input --
Blue Stretch
yes Audio Input for YPbPr --
Black Stretch
yes VGA Input(RGB)
1 (D-Sub,15 Pins)
Motion Compensation
yes Audio Input for RGB
Share with Audio for "YPbPr"
DLTI
yes DVI
share with “HDMI” port
DCTI
yes Audio Input for DVI
Share with Audio for "VGA"
Dynamic Skin Correction
yes HDMI 1.4+CEC
1
DNR
yes
Audio/CVBS Output (Composite) 1R/L+0 video output--
CCS
--
SPDIF
1（Coaxial）
Panel Specification RF Input(Antenna)
1（IEC Type）
Panel supplier
TCL USB 2.0
2
Refresh Rate
60Hz RJ45 0
Display Resolution
1920x1080 Basic Info.
Brightness (cd/m2)
350 TV System ATV:PAL B/G SECAM L/L‘ DTV:DVB-T/C/T2
Contrast Ratio
4000:1 AV System
PAL,NTSC,SECAM
Response Time
6.5ms Channels
1500
Viewing Angle (H/V)
178°/178° Chassis
MT31SR
Life Time
>30000hrs Certification
CB
Color
16.7M(8bit） DTV Certification CI+ 1.3、TDT、Canal ready
SOUND Power Supply
AC 220V-240V 50/60Hz
Speakers
Integrated speakers (Bottom side) Power Consumption-TV on
140W
Audio Power Output 8W*2
Power Consumption-Standby
Less than 0.3W
Sound Processing
Supports A2/NICAM/PAL FM
Language English/Russia
Dolby MS10 Yes Default Color of Front Cabinet
Draw Black as molded
DVSS (Dolby Virtual Surround)
-- Keyboard Position
On the Right of the back shell
DDAS (Digital Dynimic Audio System)
-- Base Stand Detachable
Yes
AVC (Auto Volume Control)
Yes
Unpackaged Dimension for Main Body (L*H*D) (mm)
BBE
--
With Base Stand (mm) 1243x769x230
SRS
--
Without Base Stand (mm) 1243x720x76
Sound Features
Smart Sound (AVC) , wide stereo,Balance
Packaged Dimension (L*H*D)
Headpone Yes
Main Body (mm) 1535x890 x160
Sound Control
8 mode Sound presets
Rock/Pop/Live/Dance/Techno/Classic/Soft/Personal)
Speaker Quantity 2
Function Base Stand
Packaged with Main Body
MHL
yes Net Weight (Kg) 18.8
ARC
yes Gross Weight (Kg)
25
PVR
yes Container Loading
CEC
yes 20 feet
102（without pallet)
OAD
yes 40 feet
220 (without pallet)
E-Stick
yes 40 feet high
330 (without pallet)
V-Chip
-- ACCESSORIES
subtitle
yes Operation Manual English(Default)
Teletext
yes Remote Control For TV control (with two batteries)
PIP/POP
-- Base Stand
Integrated Packaging
Macro Vision
-- Mini adapter --
Calendar
-- Wall Mount --
Clock/Timers
Yes
Others
Battery,User Manual.Warranty Card.
Lock
Yes Screen Size(cm)
OSD Language
English/Russia Height * Width 120.96*68.04
OSD Features
Semi-transparent Claimed Screen Size 138.78
Card Reader
--
DVD Combo
--
USB Connection
USB*2
Game
--
Screen Saver
--
hotel
yes
Demo Function
--
Picture Freeze
yes
Natural light (light sensor)
--
3D Glasses
--
Approved by:
MD Drafted by: 王宇飞
Model:L55S4610F/MT31SR-RU/LVF550ND2L CD9W00
Core Technology
High-Performance MPEG-2 /MPEG-4 Video Decoding Engine;High-quality
scaling engine& FHD motion-adaptive de-interlace;
HW Drafted by: 杨惠达
