第 7 页共 11 页
Project Name Module name OK
SIACP VERSION SIACP VERSION OK
Chassis MS306 Chassis name OK
PANEL NAME P/N of panel OK
NG
PROJECT ID >>> Select panel ID Number OK
CONFIG >>> Project Select submenu
USB UPDATE >>> USB UPDATE ok
HOTEL ENABLE
OFF
HOTEL MENU SWITCH NOT
USE
ReloadEFBItem Do Only for factory adjust OK
CONFIG submenu
ITEM Default
Setting
Description Status
Erase HDCP Key Do Only for R&D OK
Reset HDCP Key Do Only for R&D OK
UsbHdcpkey
Update
Do Only for R&D OK
5. Debugging
5.1. General Steps of debugging
According to the requirement of the order, below steps are needed for
appropriate setting.
1) Enter the Factory Menu, enable FAC HOTKEY.
2) Check Project ID and the version of software, release date displayed
at the bottom of Factory Menu.
3) Enter Design Menu, choose SERVICE MENU->Project ID, choose
corresponding Project ID number of the product (Refer to the
“V6-PROJECT -ID0**”in the BOM list).
4) Return to Factory Menu, check the Product model.
5) Choose Factory Menu->NVM RESET and press the right button of the
remote and wait until prompt OK appears.
6) Restart the set
7) According to the requirement of the order, Set the items of SHOP
INIT and Hotel Menu etc.
8) After aging under normal temperature, calibrate ADC and adjust
white balance.
