TCL RAY.DANZ User Manual

2a
Overview
Sound Bar main unit
Power button:
Press to turn the
Sound Bar main unit
on or off.
Source button:
Press to switch the
audio source among
HDMI IN/HDMI ARC/
AUX/BT/Optical/
USB modes.
LED display:
It indicates the Sound Bar status (e.g.
volume level, sound source mode, etc.).
HDMI OUT (ARC)
connector
HDMI IN
connector
AC input
power connector
AUX input
connector
Optical input
connector
USB Type A
connector
Bluetooth button:
Press to select the Bluetooth
source. Press and hold to
enter pairing mode.
Volume button:
Press to increase
or decrease the
volume level.

TCL RAY.DANZ Specifications

General

Model	RAY.DANZ
Category	Speaker System
Audio Channels	3.1
Dolby Atmos	No
Wireless Subwoofer	Yes
Bluetooth	Yes
HDMI Output (ARC)	1
Water Resistance	No
