TCL S4310 - Overview

6 7
AUX input connector
IR input connector
AUX VA input connector
AC input power connector
Optical input connector
USB Type A connector
HDMI ARC connector
Short Press: Select Bluetooth mode
Long press: Bluetooth Pairing
Short press: Switch input sources
(HDMI-ARC/Optical/AUX/AUX VA/USB/Bluetooth)
Long press: Enter subwoofer pairing
(If subwoofer disconnected)
Press to increase or
decrease the volume level.
Volume buttons:
Source button:
Power button:
Bluetooth button:
Short Press: Power On/Sleep
Long Press: Power Off
3
6
5
4
3
2
1
7
3a
Overview
Input Source LED Indicator:
HDMI-ARC: Magenta
Optical: Yellow
AUX: Green
AUX VA: Orange
USB: Cyan
Bluetooth: Blue
