TCM FB30-7V - OPERATING CONTROLS

The following symbols, found throughout this manual, alert you to
potentially hazardous conditions to the owner and the operator.
Become completely familiar with the truck before proceeding with
operating, checking and servicing.
This manual and decals affixed to the truck use the following safety
alert indications.
SIGNAL WORD
A DANGER
Ай WARNING
CLASSIFICATION
Failure to follow the instructions in the message
will likely cause a serious accident or death.
Failure to follow the instructions in the message
might cause a serious accident or death.
Failure to follow the instructions in the message
may cause personal injury or damage to the
truck or other property.
The information will help to prolong the service
life of the truck. The message is not directly
related to accident prevention.
2. OPERATING CONTROLS
CONTENTS
PICTORIAL NOMENCLATURE ................ sss 2- 1
INSTRUMENTS AND CONTROLS .. e 2-3
SWITCHES .................seeeeee 2-4
LCD METER UNIT узунун annn 2- 7
BATTERY CHARGE INDICATOR AND
DIS PLAY: sir нд tie odere Dr ER eerte 2- 8
REGENERATIVE BRAKING .................. eene 2-10
LEVERS AND PEDALS ................ eee 2-16
TRUCK BODY... aerei rnnt detener nter 2-20
OPTIONAL EQUIPMENT ............ rennen 2-28
