12
Blade installation
Blades must be installed as shown:
Front: use Yellow Blade A and Yellow Blade B
Rear: use Black Blade A and Black Blade B
Note:
The letters A and B are printed on reverse side of blades.
A
B
Front
(Yellow Blades)
Rear
(Black Blades)
Yellow Yellow
B
Black
A
Black
To disassemble the blade:
Remove the blade by pulling
upward.
To install the blade:
Match blade with the blade socket
and press down.
