TDR ROBIN PRO - Diagrams and Components

05
Diagrams
Controller
1. Blades
2. Canopy
3. Receiver Board
4. Battery
5. 5.8G Camera Board
6. Motors
7. Main Frame
360° Roll
Power Switch
Display
Speed Selection
Throttle Trim
Throttle/Rudder Stick
Rudder Trim
Video
Short Press: Photo
Long Press: Orbit Video
Forward/Backward Trim
Elevator/Aileron Stick
Left/Right Trim
Battery
Chamber
Photo/Orbit Video
Headless Mode
Button (Press down
the stick)
Auto Return Button
(Press down the stick)
