TDS Ranger - Device Hardware Overview; Front Panel Description; Back Panel Description; Expansion Slot Views

2
Device Hardware
Front Panel Back Panel
Removable CF-Cap CF-Cap
Top View- without Cap Bottom View
CompactFlash and SDIO slots
Some units do not have these slots
NOTE: Be sure to read the warranty and safety information in this
manual prior to using your unit.
PowerBoot
coin screws
PowerBoot
Module
Stylus
holder
Power
Serial
port
USB
host
CF slot #1
Type I
External
power
USB
client
CF slot #2
Type I & II
SDIO
slot
Notification
LED
Hand strap
