MAIN PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
9A09428400 MAINPCBASSY
9A09428500 MAINPCB
9A09192100 HEATSINK,AE338
9A09192300 MACHINESCREW,MS/PH3X8
9A09449300 NUT,M3
C127,C128£ 9A09433500 C,ELECT100U/50VM
C130£ 9A09270100 C,ELECT4700U/25VM
C132,C133£ 9A09433700 C,ELECT2200U/25VM
CN101 9A09270400 WAFER,5P
CN102 9A09218500 WAFER,6P
CN103 9A09270500 WAFER,16P(FFC)
CN104 9A09434500 WAFER,11P
CN105 9A09434600 WAFER,5P
CN106 9A09434700 WAFER,7P
CN501 9A09270400 WAFER,5P
D101‑D106£ 9A09434800 DIODE,1S60I
D107,D108£ 9A09434900 DIODE,1A3‑I
D109 9A09190100 ZENERDIODE,30V1/2W
D110 9A09435000 ZENERDIODE,5.1V1/2WJ
D111,D112 9A09267100 DIODE,1SS133‑T‑77
D113,D114 9A09434900 DIODE,1A3‑I
D115 9A09435000 ZENERDIODE,5.1V1/2WJ
IC101 9A09435100 IC,UPD63711GC‑8EU
IC102 9A09188600 IC,BA5813FM
IC103 9A09435200 IC,UPD789026GB‑A59‑8ES
IC104£ 9A09188800 IC,KA7805
IC105£ 9A09188900 IC,KA7808
IC106£ 9A09435300 IC,NJM78L06A
IC107£ 9A09435400 IC,NJM79L06A
IC108£ 9A09188800 IC,KA7805
IC108 9A09435500 IC,PST600D
IC501 9A09435600 IC,PCM1710U
IC502,503 9A09435700 IC,OPA2604AP
JK102 9A09435800 CONVERTOR,GP1F32T
JK501 9A09435900 JACK,RCA,2P(GOLD)
L501 9A09446400 INDUCTOR,22UHJ
MH101 9A09446500 TERMINALGND,M1698
Q101 9A09207100 TR,2SA933AS‑TP
Q501‑Q504 9A09266900 TR,2SD1936T‑AC
Q505 9A09446600 TR,DTA124ES
X301 9A09271800 CRYSTAL,5.000MHZAT‑39
X501 9A09270800 CRYSTAL,16.9344MHZ50PPM
DISPLAY PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
9A09428600 DISPLAYPCBASSY
9A09428700 DISPLAYPCB
9A09450600 PAD,20X13X5
CN301 9A09434500 WAFER,11P
D303,D304 9A09208100 DIODE,1SS133T77
D306‑D308 9A09208100 DIODE,1SS133T77
FL301 9A09449500 FLT
IC301 9A09449800 IC,UPD16312
S301‑S309 9A09193100 SWITCH,TACT
U301 9A09450500 OPTICRECEIVED,GP1U271X
H.P. PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
9A09428800 H.P.PCBASSY
9A09428900 H.P.PCB
9A09274600 WASHER,9.2X14X0.4
9A09274500 NUT,M9X0.75
IC401 9A09193300 IC,M5218AP
JK401 9A09451100 PHONEJACK
L402 9A09451200 INDUCTOR,33UH
VR401 9A09451600 VR,ROTARY50K
POWER PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
9A09429000 POWERPCBASSY[J]
9A09429040 POWERPCBASSY[US]
9A09429010 POWERPCBASSY[E]
9A09429030 POWERPCBASSY[UK]
9A09429100 POWERPCB[J,E,UK]
9A09429140 POWERPCB[US]
£ 9A09452400 POWERCORD[J]
£ 9A08660100 POWERCORD[US]
£ 9A09452100 POWERCORD[E]
£ 9A09453200 POWERCORD[UK]
9A07081100 PLUG,ROUNDPIN[US]
C201£ 9A09451900 CAPACITOR,0.01U[J,E,UK]
C201£ 9A07080700 CAPACITOR[US]
CN201 9A09434600 WAFER,5P
CN202 9A09551300 HOUSING,2P[US]
EC201,202 9A09452200 ECTERMINAL,1P[J,E,UK]
EC201,202 5760663000 ECTERMINAL,1P[US]
F201,F202 9A09452300 FUSEHOLDER[E,UK]
F201,F202£ 9A09196300 FUSE,250V630MA[E,UK]
SW201£ 9A09452000 SWITCH,PUSH,POWER[J,E,UK]
SW201£ 9A07083100 SWITCH,PUSH,POWER[US]
T201£ 9A08894100 POWERTRANSFORMER[J]
T201£ 9A09195500 POWERTRANSFORMER[US]
T201£ 9A09196100 POWERTRANSFORMER[E,UK]
−8−
