Teac CX-225iDAB - Page 5

5
CX-225iDAB/MC-DX450iDAB
75 P34/BUSRQ DAB_SYS_RST I/O O O I - -
DAB system reset(Does not use)
76 P35/BUSAK N.C I/O I O I - -
77 P36/R/W N.C I/O X OPEN
78 P37/BOOT BOOT_MODE I/O O O I H L update mode select
79 P40/CS0 N.C I/O X OPEN
80 P41/CS1 N.C I/O X OPEN
81 P42/CS2 RDS_DATA I/O I X
I - -
tuner RDS data input
82 P43/CS3 PLL_CE I/O O X I - - tuner PLL ic enable
83 P60/SCK PLL_CLK I/O O X I - - tuner PLL IC clock
84 P61/SO/SDA PLL_DOUT I/O O X I - - tuner PLL IC data out
85 P62/SI/SCL PLL_DINI/O
I X I - - tuner PLL IC data input
86 P63/INT0 T_MUTE I/O I O I - - tuner PLL IC mute
87 P64/SCOUT TUNED_IN I/O I O I - L tuned in
88 P65 STEREO_IN I/O I O I - L stereo in
rewop UCMV3.3+ UCMCCVD98
90 P66 N.C I/O X OPEN I
DNGDNGSSVD19
92 P50/AN0 KEY0 I I O I - - key0 input
93 P51/AN1 KEY1 I I O I - - key1 input
94 P52/AN2 N.C I I O I - -
95 P53/AN3/ADTRG SCROL_UP I I O I - - Scrol up
96 P54/AN4 SCROL_DWN I I O I - - scrol down
97 P55/AN5 V_PROTECT I I O I - - voltage protect
98 P56/AN6 N.C I O
99 P57/AN7 OPTION I I O I - - Version Option
100 VREFH MCU +3.3V
ADC Reference HIGH( VCC )
Use
ON Pull-up NoUse init stby Act.
Note
pin
No
O/IemaN troP
Status
Description
71 P30/RD N.C I/O X OPEN
72 P31/WR N.C I/O X OPEN
73 P32/HWR EEPROM_DATA I/O O O I - -
EEPROM DATA
74 P33/WAIT EEPROM_CLK I/O O O I - -
EEPROM CLOCK
