CX-225iDAB/MC-DX450iDAB
39 CMY1A308Z HEATSINK
40 IPOD PCB ASSY .................................................................... United on PCBA-MAIN, Refer to page 9
41 Not in use
42 COP12112B FRONT (KEY PAD) PCB ASSY
43 CJDDA23Z1F TRAVERSE UNIT , DA23Z1F
44 CLOSE SW (REMOTE SENSOR) PCB ASSY ........................ United on PCBA-FRONT, Refer to page 15
45 CFLICG1602017BTLWA LCD , IC-G160201-7BTLWA
46 CDMCCM03030R139 MOTOR (CCM03030R139)
47 COP12113B MAIN PCB ASSY
48 OPEN SW PCB ASSY ........................................................... United on PCBA-FRONT, Refer to page 15
49 CNVMW104MA1N51W MODULE , TUNER
CNVMW104FA1N51 MODULE , FM TUNER ONLY DAB
50 CNVFS2025V22A MODULE , DAB, FS2025V22A DAB
51 VIDEO PCB ASSY ................................................................. United on PCBA-MAIN, Refer to page 9
52 CKADX225SWBEUR SUB WOOFER CABINET ASSY (225IDABB)
CKADX450SWSUK SUB WOOFER CABINET ASSY (450IDABS)
┗
CAS16LP286SEZ WOOFER UNIT
53 POWER PCB ASSY ............................................................... United on PCBA-AMP, Refer to page 13
54 CLT5P048ZE TRANS , POWER , EUR (230V, 50Hz)
55 CJA2E086Z CORD , POWER
56 CSH1A009ZV SWITCH , POWER MOMS
57 COP12110B AMP PCB ASSY
58 CTB3+8JR SCREW
59 CTS3+8JR SCREW
60 CTB1.7+2.3FR SCREW
61 CTS3+10JFC SCREW Silver
CTS3+10JFB SCREW Black
62 CTS3+16JR SCREW
63 CTB3+8JFZR SCREW
64 CTB3+6JFZR SCREW
65 CTB35+22AFZR SCREW (6 X 3.5 X 1.4P X 22L Black)
66 CTB4+10FFZR SCREW
67 CTBD3+8JFZR SCREW
68 CTB3+6FFZR SCREW
69 CTB3+10JFZR SCREW
70 CHD1A012R SCREW , SPECIAL
EXPLODED VIEW
REF. NO. PARTS NO. DESCRIPTION REMARKS
