3 ADJUSTMENTS AND CHECKS
Use a screwdriver with a plastic or ceramic grip for all adjustment.
3-1 TUNER SECTION
L3 AM ANT COIL
L4
TC1
LT-1 TUNER PCB
L5
1. Set the function switch to the TUNER position.
3. Connect the signal generator output through a 75 ohm dummy
3. Connect the oscilloscope to the PHONE JACK terminal.
4. Set the signal generator as listed in the alignment chart.
3-1-2 FM adjustment
antenna to "ANT" on TUNER PCB.CN8.
2. Set the BAND switch to the FM position.
CN8
TUNER
1. Set the function switch to the TUNER position.
2. Connect the test loop antenna across the output of the signal generator.
3. Connect the oscilloscope to the PHONE JACK terminal.
4. Set the signal generator as listed in the alignment chart.
3-1-1 AM adjustment
2. Set the BAND switch to the AM position.
3-2 Adjustment and Test Points
Fig. 3-2-1
