Sampling Frequency and Number of Channels
1-15
102.4 kHz Series
Sampling Frequency (kHz) Bandwidth (kHz)
No 16bits 2ch 32bits 1ch 32bits 2ch
*102.4 42 8 4 4 N/A
*51.2 2116888
25.6 10 32 24 24 24
12.8 5 32323232
5.12 2 32323232
2.56 1 32323232
1.28 0.53 32 32 32 32
100 kHz Series
Sampling Frequency (kHz) Bandwidth (kHz)
No 16bits 2ch 32bits 1ch 32bits 2ch
*100 41 8 4 4 N/A
*50 20 16 8 8 8
20 8 32242424
10 4.1 32323232
5 2 32 32 32 32
2 0.8 32 32 32 32
1 0.4 32 32 32 32
96 kHz Series
Sampling Frequency (kHz) Bandwidth (kHz)
No 16bits 2ch 32bits 1ch 32bits 2ch
*96 40 8 4 4 N/A
*48 20 16 8 8 8
24 10 32 24 24 24
12 5 32323232
6 2.5 32 32 32 32
3 1.2532323232
1.5 0.625 32 32 32 32
65.536 kHz Series
Sampling Frequency (kHz) Bandwidth (kHz)
No 16bits 2ch 32bits 1ch 32bits 2ch
*65.536 27 8 4 4 N/A
*32.768 13 16 8 8 8
16.384 6 32242424
8.192 3 32 32 32 32
4.096 1.7 32 32 32 32
2.048 0.8 32 32 32 32
1.024 0.4 32 32 32 32
Max. number of analog input channels based on the tachometer input setting
Max. number of analog input channels based on the tachometer input setting
Max. number of analog input channels based on the tachometer input setting
Max. number of analog input channels based on the tachometer input setting
Recording Condition 3
Recording Mode: PC direct recording
Memo Voice Recording: ON or OFF
Interface to PC: IEEE1394
Remarks: Cannot select the moving average other than 1 (one) at the Sampling Frequency settings shown
with *(asterisk).
