6
MC-DX50i
REF.NO. PARTS NO. DESCRIPTION REMARKS
1 56-04DX50I00B10 FRONT CAB (HIPS) 931980 428C
2 56-05DX50I00B10 REAR CAB(HIPS) DAB 931980
3 56-07DX50I10910 BACK LIHGT BRACKET 1 (ABS) WHITE
4 56-07DX50I30910 REMOTE CONTROL INCEPT BRACKET (ABS) WHT
5 56-07DX50I40010 LOAD BRACKET (ABS)
6 56-09DX50I00B10 IPOD BRACKET BOTTOM BOARD (ABS) BLACK
7 56-09DX50I10B10 IPOD BRACKET BASE (ABS) BLACK
8 56-22DX50I00B10 CD COVER (ABS) BLACK
9 56-22DX50I20B10 POWER COVER (ABS) BLACK
10 56-33DX50I00B10 IPOD BRACKET FIXING (ABS) BLACK
11 56-54DX50I00A10 FUNCTION KNOB GROUP-1(ABS) SILVER
12 56-54DX50I10A10 FUNCTION KNOB (ABS) BLACK
13 56-54DX50I20A10 FUNCTION KNOB GROUP-2(ABS) SILVER
14 56-57DX50I30010 CD LENS (PMMA)
15 56-57DX50I10010 BACK LIGHT LENS 1 (PMMA)
16 56-57DX50I40010 STANDBY LENS (PMMA) MILK
17 56-69DX50I00000 LOADER PLATE -L(ABS)
18 56-69DX50I00100 LOADER PLATE -R(ABS)
19 56-69DX50I00200 PCB PLATE (ABS) BLACK
20 56-78DX50I00010 FUNCTION KNOB RING (ABS) ELECTROPLATE
21 57-08DM23000020 PETP PLATE
22 57-26DX50I00020 FILTER SHEET
23 57-47DX50I00020 DISPLAY LENS T=1mm (PC)
24 58-263102300120 RUBBER FOOT(BLK)(PORON) DIA10mm T=3mm
25 58-26DX50I00021 RUBBER FOOT (PORON) 16x15x3mm
26 58-58DX50100020 RUBBER PLATE 28X17X2mm
27 61-11CDX0900020 DS MTEAL PLATE
28 61-11DX50100020 WEIGHT STEEL 1 115X90mm
29 61-11EXM5M00020 METAL PLATE 9.5x5x0.8mm
30 61-30DX50I00020 KNOB COVER (ALUMINUM)
31 66-120330180121 MACHINE SCREW MS/PH 3x8mm (BLACK)
32 66-120530180121 MACHINE SCREW MS/KH 3x8mm (BLACK)
33 66-150526150321 SELF TAPPING SCREW TB/KH 2.6x5
34 66-140326160121 SELF-TAPPING SCREW TA/PH 2.6x6mm (BLACK)
35 66-140326180121 SELF-TAPPING SCREW TA/PH 2.6x8mm (BLK)
36 66-140326180321 SELF-TAPPING SCREW TA/PH 2.6x8mm
37 66-151426180321 SCREW TB/BWH 2.6x8mm HD8.5mm
38 66-140330180121 SELF-TAPPING SCREW TA/PH 3x8mm (BLACK)
39 66-140330210121 SELF-TAPPING SCREW TA/PH 3x10mm(BLACK)
40 66-140330212121 SELF-TAPPING SCREW TA/PH 3x12mm (BLACK)
41 66-140530210121 SELF-TAPPING SCREW TA/KH 3x10mm (BLACK)
42 66-140826212321 SELF-TAPPING SCREW TA/WH 2.6x12mm
43 66-141430210321 SCREW TA/WH 3x10mm HD:10mm
44 19-50DX50I00020 SPEAKER BOX UNIT-L
45 19-50DX50I00120 SPEAKER BOX UNIT-R
46 20-71DX50I00020 CD LOADER #VSH-L33C-0762L (FOR DA23SR)
47 05-DX50I0100001 PCBA-MAIN "UL"
48 05-DX50I0500000 PCBA-MCU/KEY "UL"
49 05-DX50I0800000 PCBA-IPOD "UL"
50 05-DX50I3000000 PCBA-CD "UL"
51 66-150230180123 HARDEN SCREW BTTB 3x8mm AB(BLACK)
52 67-021400000020 NUT M4mm
53 68-112403101000 METAL WASHER 4x10x1mm
54 13-05DX22I00020 LCD DISPLAY
55 PCBA-CD BACKLIGHT................................................. Included in Ref. No. 47 PCBA-MAIN.
Refer to page 8.
56 PCBA-AUX&PHONE..................................................... Included in Ref. No. 47 PCBA-MAIN.
Refer to page 8.
57 PCBA-S-VIDEO ............................................................ Included in Ref. No. 47 PCBA-MAIN.
Refer to page 8.
58 PCBA-RESET................................................................ Included in Ref. No. 47 PCBA-MAIN.
Refer to page 8.
EXPLODED VIEW
PARTS LIST
