7
MC-DX50i
59 41-172111000310 POWER SWITCH
60 45-114180310061 AC POWER CORD
61 05-DX32I0300000 PCBA-STANDBY -120V
62 05-DX50I0700000 PCBA-SUB POWER
63 05-DX50I0810000 PCBA-RCA/D-S JACK
64 18-203DX0150120 H/TRANSFORMER EI66 120V 60Hz TU0000700
65 190021153300120 SPEAKER5.25"8Ω30W#JHD-SA130-12
66 43-500000002020 AC CORD BUSHING T=1.6mm #4N4
67 48-16DX50100220 SUBWOOFER LED PCB
68 56-22CDX0908000 PCB COVER (ABS)
69 56-78CD10I0B000 SAFEGUARD RING/SUB (ABS)
70 56-85DX50I00B10 AKER BOX PANEL (HIPS) 931980 428C
71 56-87CDX090B000 PLASTIC TUBE (ABS)
72 56-87DX50I00010 LED COVER (PMMA) MILK
73 58-263253150020 RUBBER FOOT (PORON) DIA25mm T=15mm
74 58-58DX01500320 CUSHION (EVA) 106x40x1mm
75 58-58DX02500020 CIRCLE CUSHION DIA(60+35)x1.5mm
76 58-73DX50I00000 WOODEN BOX
77 61-11V600000020 PCB BRACKET
78 61-11V820010020 PCB FIX BRACKET (B) (T0.8mm) #DV-8200
79 61-33DX50I00020 SUB.REAR PANEL 120V "TEAC"
80 61-48DX01500020 HEATSINK A
81 66-120230160121 MACHINE SCREW MS/BH 3x6mm (BLACK)
82 66-120240212121 MACHINE SCREW MS/BH 4x12mm (BLACK)
83 66-140230210321 SELF-TAPPING SCREW TA/BH 3x10mm
84 66-140230212121 SELF-TAPPING SCREW TA/BH 3x12mm(BLACK)
85 66-140230214121 SELF-TAPPING SCREW TA/BH 3x14mm(BLACK)
86 66-141430214121 SCREW TA/BWH 3x14mm(HEAD 10mm)(BLACK)
EXPLODED VIEW PARTS LIST
REF.NO. PARTS NO. DESCRIPTION REMARKS
