ENGLISH
7
turntable
screw fixing the turntable for transportation
Before use, completely loosen the screw by turning it clockwise with a coin or
screwdriver.
When you transport the unit, turn the screw counterclockwise to fix the
turntable.
cue-lever
Use this lever to lift the tone arm.
tone arm holder
tone arm
speed selector
45 RPM adaptor
Speakers (stereo)
VOLUME knob (power switch)
Turn the knob clockwise till a click is heard to turn the unit on. Then turn the
knob to adjust the volume.
When not in use, turn the knob counterclockwise till a click is heard to turn
the unit off.
PHONO, AM, FM buttons
Press the PHONO button to play a record.
To listen to the radio, press the AM or FM button.
Display panel
When the unit is on, this display will light.
TUNING knob
Turn this knob to tune in a station.
L
K
J
I
H
G
F
E
D
C
B
A
The equipment draws a nominal amount of power from the AC outlet even with
its POWER switch in the OFF position.
