Specifications
General
AC adapter power
Input............................... AC 100–240 V, 50–60 Hz
Output........................... DC 12.0V, 1.0A, 12.0W max.
Power consumption
Standby .............................................. 0.3 W or less
On (33, 45, 78).................................. 2.0W or less
Weight....................................... 10.5kg (23 1/4lb)
Operating temperature range .......................5°C to 35°C
Dimensions (W × H × D) (including protrusions)
When the dust cover is closed
450 × 148 × 351 mm (17 3/4" × 5 7/8" × 13 7/8")
When the dust cover is open
450 × 420 × 410 mm (17 3/4” × 16 5/8" × 16 1/4")
When the dust cover is removed
450 × 135 × 351 mm (17 3/4” × 5 3/8” × 13 7/8”)
(when tonearm at highest position)
o Performance data is specified at 20°C.
Included accessories
45 RPM adapter × 1
Counterweight × 1
Headshell × 1
Ortofon 2M Red (MM-type) pre-installed
Turntable (platter) × 1
Flat belt × 1
Pulley cover × 1
Dust cover × 1
Hinges × 2
Foot height adjustment washers × 4
Tonearm height adjustment hex wrench (2.5mm) × 1
Tonearm lifter height adjustment hex wrench (1.5mm) × 1
RCA audio cable × 1
Ground wire × 1
AC adapter (GPE018S-120100-Z) × 1
Cartridge Alignment Gauge × 1
Owner’s manual (this document, including warranty) × 1
o For information about the warranty, users living in the USA and
Canada should see page82 and the back cover (warranty
document). Users living in Europe and other regions should
see page83.
o Specifications and appearance are subject to change without
notice.
o Weight and dimensions are approximate.
o Illustrations in this owner’s manual might differ slightly from
production models.
Turntable (platter)
Drive system
Rotation detection type high-precision control belt drive
Motor................................................DC motor
Rotation speed..................... 33 1/3 rpm, 45 rpm, 78 rpm
Wow and flutter.................................... 0.1% or less
Turntable (platter) ..................Acrylic, 30cm (12") diameter
Cartridge
Type ....................................................... MM
Output voltage.......................... 5.5 mV (1 kHz, 5 cm/s)
Tracking force............................................. 1.8 g
Cartridge weight .......................................... 7.2 g
Included headshell weight
10g (including screws, nuts and wires)
o The lifespan of a stylus depends on the use conditions but
is usually about 1000hours.
o Replacement record stylus model: Ortofon 2M Red
Tonearm
Tonearm type ............... Static-balanced S-shaped tonearm
Effective tonearm length .............................. 223 mm
Suitable cartridge weight ............................. 4.0–13g
14–23g
(with the included headshell)
Overhang ...............................................18 mm
Tonearm height adjustment range ................ about 6 mm
Analog audio outputs
Connectors ........................ XLR connectors (1 L/R pair)
RCA connectors (1 L/R pair)
