Water
7
Fill Up The Cylinder #2
With Water
Cylinder #2Cylinder #1
Cylinder #2
Cylinder #2
Cylinder #1
Hydraulic module
Push to the end Push to the end
Cylinder #2Cylinder #1
Press down the piston of
cylinder #2 to the bottom
insufficient
water
water
leakage
excess
air
excess
air
P3
(Soft Tube)
P3
(Soft Tube)
If hydraulic module experiences above failures, back to page 5-6, step 4-7 and fill up the cylinder with water
Notices!! Very Important - Hydraulic Module
Notice 1 : Ensure Hydraulic Module is without the above failures before assembly of each model
Notice 2 : During assembly of each model, Do not Push or pull Cylinder #2 when hydraulic module is installed
Cylinder #1
Cylinder #2
In these cases, go back to page 6-7, step 4-7 and fill up the cylinder with water
Pull
Push
Example : Ostrich
Hydraulic Module Testing
