Team C Patron - Page 18

14
28
Rear suspension
Aufhaengung hinten
Apply threadlocker(screw cement)
Verwenden sie Schraubensicherungslack
Screw
Cement
TR4059 M3x22 Screw
M3x22 Schraube
…2
………2
TR4055 M3 Nut
M3 Mutter
TR4059 M3x12 Screw
M3x12 Schraube
……6
TS4011
Rear Shock Tower
Daempferbruecke hinten
TR4059 M3x22
TR4055 M3
TR4059 M3x8 Screw
M3x8 Schraube
………2
TR4059 M3x12
TR4059 M3x8
TR4059
M3x8
TR4059 M3x12
TR4055 M3
TS4018
Rear bumper stick-R
Rammerhalter hinen rechts
TS4018
Rear bumper stick-L
Rammerhalter hinten L
TR4059 M3x12
Bag-D
29
2.8x1.9 O-Ring
……………………4
………………………8
TG2040/TG2041 2.3 E-ring
2.3 E-Ring
T02068 Shock Piston
Kolbenplatte
………………4
T02069 2.8x1.9 O-ring
…………………8
3.1x1Plastik Scheib.
T02069 3.1x1 Plastic Washer
T02137 5.8x6 Ball stud
5.8 Kugelpfanne
T02114 5.8 Ball End
…………………4
5x8x6 Kugelkopf
………………………4
TS4059/TS4060 8x1 O-ring
8x1 O-Ring
Daempfer
Shock Absorber
TG2040
Put a little oil
Etwas oelen
TG2041
T02068
TG2040
TG2040
TG2041
TG2041
T02068
T02137
T02114
…………………4
T02069 2.8x1.9
T02069 3.1x1
T02069 2.8x1.9
T02069
TS4059
T02069 2.8x1.9
T02069 3.1x1
T02069 2.8x1.9
T02069
TS4060
T02137
T02114
TS4059
TS4059
TS4060
TS4060
Front-Short
Vorne kurz
x2
Rear-Long
Hinten lang
x2
Put a little oil
Etwas oelen
Assemble as many times as specified
In angegebener Stueckzahl fertigen
x2
Bag-E
