The battery is not included with the unit as supplied.
For frequent employment, the use of a
rechargable
nickel-cadmium battery instead of a
Alcali
Battery -Block is advisable. The NC rechargeable battery can be recharged with a
suitable charging device through the integral charge jack
(
6 ) [ LADEN
1,
without having to
open the battery compartment. The condition of the battery must be testet from time to time.
A discharged or “dead” battery must be removed from the unit immediatly. A leaking battery
can cause serious demage to the radio.
Radio operation
After the battery has been correctly inserted, radio operation can be undertaken.
1.
2.
3.
4.
5.
Receiving
The device is switched on by the knob
(
3
)
a.
Set the volume control
[
Lautst.
]
(
2
)
to
the desired level. If the unit is switched on a green LED [RX] lights up
(
11
)_
Squelch
Interfering noise can suppressed with the Squelch knob
[
RAUSCH.
1.
The controller is
first turned to the left hand-stop, the receiver
signal. Subsequently the controller is turned
no longer interfering.
is opened, the device whistle or receives a
clockwise only so far that the noise is just
Channel selector
With the channel selector
(
4
)
on the right
channels
@
and
@.
Position A=channel
,
side of the unit, it’s possible to select two
l9=27,185MHz
, Position
&channel283
27,285MHz.
Radio operating is only possible with the counter-station at coinciding
channel selector position or channel frequency.
Transmitting
The push to talk key
(
5
)
on the right hand side of the device is pressed to transmit.
When transmitting, the microphone
(
7
)
addressed with normal loudness at a distance of
5-10
cm. As soon as the message has been passed, the push to talk key is released, the
device switches back to receive.
Signal Tone
If the Signal key ( 9
)
is pushed a signal tone is to hear in the speaker (
IO
).
If the signal
key is simultaneous pushed with the “push to talk key”
(
5
),
the signal tone is only to
hear in the partner-station.
Servicing of the TEAM Shorty
There are no user adjustable or user serviceable parts inside the radio. The casing must be
not opened independent repairs or adjustment must not carried out, since each modification
or unauthorised intervention will immediatly cancel all and any guarentee or repair claims,
they are also likely to result in nonconformity of the approval which
-will
render the set illegal.
In event of a defect becoming apparent, contact a properly equipped and authorised dealer.
