TechLogix Networx TL-CPT-HD01 - System Connection; Specification

4
TL-C-HDCP!User!Manual
www.tlnetworx.com,
2. System!Connection!
The!figure!below!illustrates!a!typical!connection!that!can!be!utilized!with!TL-CPT-HD01:!
!
3. Specification!
Techn ical! !
Input!
1!x!HDMI!IN!
Input!Signal!Type!
HDMI!2.0!
Input!Resolution!Sup p o rt !
VESA:!
800x600@60Hz,!1024x768@60Hz,!
1280x768@60Hz,!1280x800@60Hz,!
1280x960@60Hz,!1280x1024@60Hz,!
1360x768@60Hz,!1366x768@60Hz,!
1440x900@60Hz,!1600x900@60Hz,!
1600x1200@60Hz,!1680x1050@60Hz,!
1920x1200@60Hz!
SMPTE:! !
720x480@60Hz,!720x576@60Hz,!1280x720@60Hz,!
