DISPLAYPORT TO DVI/HDMI/DP 3-IN-1 ADAPTER
EN
5.0 OPERATION
1) Connect DisplayPort of this product to Macbook Pro or Macbook Air or other DisplayPort displays
2) Connect HDMI Female port of this product to an HDMI monitor
3) Connect DVI Female port of this product to a DVI monitor
4) Connect DP Female port of this product to a DP monitor
6.0 CONNECTION DIAGRAM
DisplayPort Source
HDMI
Cable
DVI
Cable
DP
Cable
HDMI MonitorDVI Monitor DisplayPort Monitor
