Dear customer
Thank you for purchasing this product. For optimum performance
and safety, please read these instructions carefully before connecting,
operating or adjusting this product. Please keep this manual for future
reference.
IntroduCtIon
The product is designed to use two pairs of loudspeakers connected to
oneamplifier.Thepairsofloudspeakerscanbeusedsimultaneouslyor
separately.Theproductfeaturesametalhousingandtwoseparaterocker
switches. This design eliminates interference and volume reduction.
PACKAGe ContentS
• Mainunitx1
• UserManualx1
ConneCtIon
1)Failuretoobservethefollowinginstructionscanleadtodamagetothe
product, the loudspeakers and the amplifier.
2)Turn offtheamplifier beforeconnecting thecables. Checkall cable
connections before turning on the amplifier.
3)Insert the strands correctly into the connections. Failure to do so
poses a risk of short-circuiting.
4)Usesuitableloudspeakercablesonly.Contactaprofessionalincase
of doubt.
5)Connect passive loudspeakers to the loudspeaker outputs only (no
activeloudspeakers).
6)Connectstheinputsource(e.g.DVD,PC,Mobile,TV)totheamplifier;
connects the amplifier to the AMP input terminals; connects the
loudspeakerswiththeSPEAKEROUTPUTterminals.
7) Refer to the user manual of the amplifier and the loudspeakers
concerningtheirrespectivetechnicaldataandanyspecialinformation
concerning their connections.
oPerAtIon
• Turnontheamplifierandbeginaudioplayback.
• Usetherockerswitchestoselectoneorbothloudspeakerpairs(ON=
turnon/OFF=turnoff).
If only one pair of loudspeakers is connected, the rocker switch
for the unused connection must be turned OFF. Otherwise correct
operation is not possible.
www.techly.com
2 Way Speaker Switch with Terminal Clamps
USER'S MANUAL
EN
www.techly.com
OBSERVE THE IMPRINTS OF THE CONNECTIONS
SPeCIFICAtIonS
SAFetY PreCAutIon
INTENDED USE
Wedonotpermitusingthedeviceinotherwayslikedescribed
inthisuser’smanual.Usetheproductonlyindryinteriorrooms.
Notattendingtotheseregulationsandsafetyinstruction
might cause fatal accidents, injuries, and damages to persons and
property.Themanufacturer/supplierassumesnoliabilityfordamages
causedbyfailuretocomplywiththeintendeduse.
To reduce risk of electric shock,
this product should ONLY
be opened by an authorized
technicianwhenservice is required.Disconnectthe productfrommains
andotherequipmentifaproblemshouldoccur.Donotexposetheproduct
to water or moisture.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
• Your product is not a toy and is not meant for children, because it
contains small parts which can be swallowed and can injure when
usedinappropriately!
• Please install the system and devices attached to it in a way that
personscannotbeinjured,orobjectsnotbedamagedforexampleby
dropping or stumbling.
• Please remove the packing materials, because children may cut
themselves on them while playing. Furthermore, there is a risk of
swallowing and inhalation of incidentals and insulating material.
• Avoid places with high temperatures, or humidity, or places which
mightcomeintocontactwithwater.Donotinstalltheproductclose
toopeningsofairconditioners,oratplaceswithanexcessiveamount
of dust or smoke.
•Donotinstalltheproductatplacessubjecttovibration,oroscillation
•Donotmodifyandaltertheproductandanyaccessories!Donotuse
anydamagedparts.
•Keepenoughspacearoundalldevicesforagoodventilationandfree
motion and to avoid damages.
Maintenance:
Cleanonlywithadrycloth.Donotusecleaningsolventsorabrasives.
Warranty:
Noguaranteeorliabilitycanbeacceptedforanychangesandmodifications
of the product or damage caused due to incorrect use of this product.
IncompliancewithEUDirectiveWEEEthisproductismarkedwith
thissymbol.Itmeansthatusedelectricalandelectronicproducts
should not be mixed with general household waste. There is a
separatecollectionssystemfortheseproductsincompliancewith
WEEE directive, otherwise contaminative and hazardous
substances can pollute the environment.
WiththeCEsign,Techly
®
ensures that the product is conformed to
thebasicEuropeanstandardsanddirectives.
Imprint Meaning
+ Positive connection
- Negativeconnection
RIGHT Rightconnection
LEFT Left connection
SPEAKER OUTPUT Loudspeaker output
AMP INPUT Amplifier input
Load 150WRMSperchannel
Impedance 4-16Ω
Cable length max.50m
Wire cross section max.2.5mm²
Operating conditions
-25to+85ºC,20–75%RH
Storage conditions
-25to+85ºC,20–75%RH
Speaker Speaker
Audio Amplifier
