INSTALLATION REQUIREMENTS
1.HDMI source device (computer graphics card, DVD, PS3, HD
monitoring equipment, etc..)
2.HDMI display device like SDTV, HDTV and projector with HDMI
port.
3.Network cables: UTP/STP Cat6/6A/7 networking cables, which
followingthestandardofEIA568B
PANEL DESCRIPTION
1. Transmitter unit (TX)
7
➊
Powerinput(DC5V)
➋
EDIDdipswitch
➌
IRSignaloutputtoconnectwithblasterextensioncable
➍
RJ45signaloutput
➎
HDMI input
➏
Power/signalindicator
➐
Resetbutton
2. Receiver unit (RX)
➊
Length:foradjustingthelengthofnetworkcable
➋
RJ45signalinput
➌
RJ45 indicator led, it lights on all the time with HDMI signal
transmission,flasheswithnosignaltransmission
➍
DC5Vpowerinput(OPTIONAL)
➎
HDMI signal output
➏
IRsignalinputtoconnectwithIRreceiverextensioncable
