INTRODUCTION
This VGA extender incorporates HDBitT transport technology to
extend VGA signal over single cat.5/6. It saves cable cost and
supportsRGBHVsignalinput.ItcanbewidelyappliedinTVfiled,HD
video camera system and multimedia education fields, etc….
FEATURES
• ApplyadvancedHDBitTtransportprotocol
• ExtendVGAsignaloverCAT5e/6cable
• Transmit1080psignalupto120meters
• SupportRGBHVinput
• Support3.5mmaudiojack
• High-endaluminumalloyenclosuredesign
• Wall-mountabledesignforconvenientinstallation
PACKAGE CONTENTS
• VGAEXTENDERTXx1pc
• VGAEXTENDERRXx1pc
• PowersupplyDC5V/2Ax2pcs
• 3.5mmaudiocablex1pc
• User’smanualx1pc
Note: above accessories are contented in the regular package for
thekitwithtransmitterand receiver. If buyVGAExtenderTXorVGA
ExtenderRXseparately,thepackagecontentswouldbedifferent.
INSTALLATION REQUIREMENTS
1.SourcedevicewithVGAoutputport(computergraphicscard,DVD,
PS3,HDmonitoringequipment,etc..)
2.DisplaydevicewithVGAinputport
3.UTP/STPCat5e/6networking cables,whichfollowingthestandard
ofEIA568B
PANEL DESCRIPTION
1. VGA EXTENDER TX (Sender)
7 8
➊
Audioinput
➋
Powerinput(DC5V)
➌
Power status indicator
➍
Resetbutton
➎
HDBitTsignaloutput
➏
Datatransmissionindicator
➐
Network connection indicator
➑
VGAsignalinput
2. VGA EXTENDER RX (Receiver)
7 8
➊
Audiooutput
➋
Powerinput(DC5V)
➌
Power status indicator
➍
Resetbutton
➎
HDBitTsignalinput
➏
Datatransmissionindicator
➐
Network connection indicator
➑
VGAsignaloutput
INSTALLATION PROCEDURES
Make a Cat.5/6 network cable
FollowthestandardEIA-568B:
1-Orange/white
2-Orange
3-Green/white
4-Blue
HDBitT VGA Extender
HDBitT VGA Extender
