720P/1080P: Press 720P/1080P button to choose output HDMI
signalas720P@50/60Hzor1080P@50/60Hz
LED: Output HDMI signal 720pwhen LED is red and 1080p when
green
TROUBLE SHOOTING
Noimageoutput?
A: 1) Please check and make sure all the connection is correct,
signal LED indicator lights up normally and HDTV channel is
chosencorrectly.
 2) Checkwhether theoutput HDMIsignal issupportedby the
HDTV.
TECHNICAL PARAMETER
This product is marked with this symbol. It means
that used electrical and electronic products should
not be mixed with general household waste. There is
a separate collections system for these products in
compliancewithEUDirectiveWEEE.
With the CE sign, Techly
®
ensures that the product is
conformedtothebasicEuropeanstandardsanddirectives.
Maintenance: Clean only with a dry cloth. Do not use cleaning
solvents or abrasives.
Warranty: Noguaranteeorliabilitycanbeacceptedforanychanges
and modifications of the product or damage caused due to incorrect
use of this product.
CVBS TO HDMI MINI CONVERTER
Power adapter DC5V/1A
HDMI signal HDCPcompliant
CVBS input
DetectPAL/NTSCautomatically
1.0Vp-pImpedance:75Ohm
DDC Signal 5Vp-p(TTL)
TMDS signal 0.5-1.0Vp-p(TMDS)
Power Consumption 2.5W
Dimension (L*W*H) 105.5*64.5*23mm
