C.1
By removing the screw 2, you can
remove the head from the mounting
base for angle adjustments.
C.2
Hold the base to the installation
surface and mark the screw holes
with a pencil.
C.3
Hold the base to the surface you
want to install it on mark the screw
holes with a pencil drill holes on
the marks into the wall insert the
dowels drive screws through the
holes of the mounting base.
Attention: asure that you use the
correct dowels for your desired
surface the dowels in the package
contents are for normal concrete
walls.
D.1
Put back the front cover. Important:
the arrows must match.
turn the front cover to close it
correctly (tighten the weatherproof
seal)
