1.LED: Press this button to power the LEDs of the sliders on and off.
2.Input:
Press this button to switch among all the input modes. The default input is TAPE input mode.
3.
EQ/BYPASS: Press this button to disable the EQ effect on the EQ5300. Press it again to activate.
When the EQ effect is activated, the signal passing through the EQ5300 will be changed depending on
the position of the EQ sliders.
4.Range
: Press this button to increase the signal by ±6dB or ±12dB. The default setting is ±6dB.
5.
Display: Press this button to switch the screen display among all the display modes.
6.Power
: Press this button to power the unit on and off.
7.High/Low
: Press this button to select spectrum display mode.
8.
Dual 10 Band Equalizers: Use the sliders to increase or decrease the respective frequencies. The
equalization points are 30Hz,64Hz,125Hz,250Hz,500Hz,1KHz,2KHz,4KHz,8KHz and16KHz. The
adjustment range is ±12dB.
EQ5300 Front Panel
134 267 5
8
EQ5300
