9 Channel Mode (DMX):
When use the LG500x together with a DMX controller, set the DIP to 10 on, then use the DMX controller to adjust the
settings of CH1, CH2, CH3 and CH4, CH5, CH6, CH7, CH8 to show different effect.
DMX512 Function:
Channel
Value
Function
CH1
0-199
Speed(Connect with
CH2,3,4,5,6,7,8≥32)
200-249
Auto-pilot
255
Sound-Activated
CH2,3,4,5,6,7,8
(each channel control one
separate LED area, total 7 LED
areas.)
0-31
NULL
32-127
Strobe
128-134
NULL
135-255
RGB output in turns
Channel 9
(this channel control all the LED)
0-31
NULL
32-127
Strobe
128-134
NULL
135-255
RGB output in turns
